Vehicle Speed Sensor Tests

WARNING: This page is about a different car, the 2002 Nissan Pathfinder. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: For wheel sensor or rotor, see WHEEL SENSOR OR ROTOR under TROUBLE DIAGNOSES FOR SELF-DIAGNOSTIC ITEMS in ANTI-LOCK - PATHFINDER & QX4 article in BRAKES.

For vehicle speed sensor tests, see Fig 1.

Fig 1: Identifying Vehicle Speed Sensor Tests

Courtesy of NISSAN MOTOR CO., U.S.A.
