Removal and Installation of BCM: Removal

WARNING: This page is about a different car, the 2006 Nissan Quest. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: If possible, before removing BCM, retrieve current BCM configuration to use for reference when configuring brand-new BCM after installation. Refer to , "CONFIGURATION ".
  1. Disconnect negative battery cable.
  2. Remove instrument panel storage bin. Refer to , "REMOVAL AND INSTALLATION ".
  3. Remove instrument lower panel LH. Refer to , "REMOVAL AND INSTALLATION ".
  4. Disconnect switch assembly.
  5. Remove screw and release BCM.
  6. Disconnect connectors and then remove BCM.
    Fig 1: Removing Screw And Releasing BCM
    G04201236Courtesy of NISSAN MOTOR CO., U.S.A.
