Terminals And Reference Value For Unified Meter And A/C Amp.

WARNING: This page is about a different car, the 2003 Nissan Murano. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Unified Meter And A/C Amp. Terminals And Reference Value Chart

Courtesy of NISSAN MOTOR CO., U.S.A.
