Alphabetical Index
NOTE:
If DTC U1000 or U1001 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000, U1001. Refer to "
DTC U1000, U1001 CAN COMMUNICATION LINE
".
Fig 1: Consult-II - DTC Index (4 Of 6)
Courtesy of NISSAN MOTOR CO., U.S.A.
Fig 2: Consult-II - DTC Index (5 Of 6)
Courtesy of NISSAN MOTOR CO., U.S.A.
Fig 3: Consult-II - DTC Index (6 Of 6)
Courtesy of NISSAN MOTOR CO., U.S.A.
