Fuel Tank Temperature Sensor

  1. Remove "fuel level sensor unit and fuel pump".
  2. Check resistance between "fuel level sensor unit and fuel pump" terminals 4 and 5 by heating with hot water or heat gun as shown in the figure.
    FUEL TANK TEMPERATURE SENSOR RESISTANCE

    Temperature °C (°F) Resistance kΩ
    20 (68) 2.3 - 2.7
    50 (122) 0.79 - 0.90
    Fig 1: Checking Fuel Level Sensor Resistance
    G04196736Courtesy of NISSAN MOTOR CO., U.S.A.
