Removal and Installation: Removal

WARNING: This page is about a different car, the 2012 Nissan Pathfinder. However, it is still accessible from the selected car via links, so may be relevant.
  1. Using a suitable tool, release the metal clip and pawls, then lift the main power window and door lock/unlock switch and finisher (2) upward as an assembly.
    CAUTION: Wrap a cloth around suitable tool to protect components from damage.
  2. Disconnect the harness connectors, then remove the assembly from front door finisher.
  3. Remove the three screws (A) and separate the main power window and door lock/unlock switch (1) from the switch finisher (2).
    Fig 1: Identifying Main Power Window And Door Lock/Unlock Switch, Switch Finisher And Screws
    G08168508Courtesy of NISSAN NORTH AMERICA, INC.
