Connector End Views

Fig 1: Power Window System Connector End Views (1 Of 6)

Courtesy of NISSAN NORTH AMERICA, INC.

Fig 2: Power Window System Connector End Views (2 Of 6)

Courtesy of NISSAN NORTH AMERICA, INC.

Fig 3: Power Window System Connector End Views (3 Of 6)

Courtesy of NISSAN NORTH AMERICA, INC.

Fig 4: Power Window System Connector End Views (4 Of 6)

Courtesy of NISSAN NORTH AMERICA, INC.

Fig 5: Power Window System Connector End Views (5 Of 6)

Courtesy of NISSAN NORTH AMERICA, INC.

Fig 6: Power Window System Connector End Views (6 Of 6)

Courtesy of NISSAN NORTH AMERICA, INC.
