Steering Column Assembly

Check each part of steering column assembly for damage or other malfunctions. Replace entire steering column assembly if any parts are damaged.
Measure steering column rotating torque using Tool. Replace steering column assembly if outside the specification.
Tool number (A): ST3127S000 (J-25765-A) Rotating torque: Refer to "STEERING COLUMN ".

Fig 1: Measuring Steering Column Assembly Rotating Torque Using Preload Gauge
Courtesy of NISSAN NORTH AMERICA, INC.
Measure the length (L) as shown if vehicle has been involved in a minor collision. Replace steering column assembly if outside the specifications.
Steering column length (L): Refer to "STEERING COLUMN ".

Fig 2: Identifying Steering Column Length
Courtesy of NISSAN NORTH AMERICA, INC.
Check each part of steering column assembly for damage or other malfunctions. Replace if there are any abnormal conditions.
Check the steering wheel play, neutral position steering wheel, steering wheel turning force, and front wheel turning angle. Refer to "INSPECTION "
Check tilt mechanism operating range and telescopic mechanism operating range as shown below.
Tilt mechanism operating range (A): Refer to "STEERING COLUMN ".

Telescopic mechanism operating range (B): Refer to "STEERING COLUMN ".

Fig 3: Identifying Tilt Mechanism And Telescopic Mechanism Operating Range
Courtesy of NISSAN NORTH AMERICA, INC.
