Removal and Installation: Removal

  1. Remove NATS antenna amp. Refer to "REMOVAL AND INSTALLATION ".
  2. Release pawls and remove the push-button ignition switch (1).
    Fig 1: Identifying Push-Button Ignition Switch
    G09605079Courtesy of NISSAN NORTH AMERICA, INC.
