ECO Mode Indicator Lamp

DESIGN/PURPOSE

The ECO mode indicator lamp inform the driver that the vehicle is in ECO mode.

Courtesy of NISSAN NORTH AMERICA, INC.

SIGNAL PATH

• Combination meter receives ECO mode switch signal (ON/OFF) from BCM via CAN communication. Based on the signal, BCM transmits ECO mode signal to ECM via CAN communication.
• ECM transmits ECO mode indicator signal to combination meter via CAN communication. Based on the signal, combination meter illuminates ECO mode indicator lamp.

LIGHTING CONDITION

When all of the following conditions are satisfied.

• Ignition switch: ON
• The ECO mode switch is pressed when the ECO mode indicator lamp is OFF

SHUTOFF CONDITION

When any of the condition listed below is satisfied.

• Ignition switch: Other than ON
• The ECO mode switch is pressed when the ECO mode indicator lamp is ON.
