Fuel Pump Relay

For troubleshooting of the fuel pump relay, see Fig 1 and Fig 2 .

Fig 1: Fuel Pump Relay Diagnostic Flow Chart (1 Of 2)

Courtesy of AMERICAN HONDA MOTOR CO., INC.

Fig 2: Fuel Pump Relay Diagnostic Flow Chart (2 Of 2)

Courtesy of AMERICAN HONDA MOTOR CO., INC.
