Security Control Unit Input Tests: 3.2TL

Remove glove box. Disconnect security control unit connectors. Inspect connectors and terminals. Check for bent, loose or corroded terminals. Perform security control unit input tests. See Fig 2 -8. If security control unit inputs are okay, replace faulty security control unit.

Fig 1: Security Control Unit Connector Terminals (2.5TL)

Courtesy of AMERICAN HONDA MOTOR CO., INC.

Fig 2: Security Control Unit Input Test (2.5TL & 3.2TL - 1 Of 2)

Courtesy of AMERICAN HONDA MOTOR CO., INC.

Fig 3: Security Control Unit Input Test (2.5TL & 3.2TL - 2 Of 2)

Courtesy of AMERICAN HONDA MOTOR CO., INC.

Fig 4: Security Control Unit Input Test (3.2TL - Supplement)

Courtesy of AMERICAN HONDA MOTOR CO., INC.
