Repair Procedure: Notes

NOTE:

Review the Service Precautions before doing repairs or service .
In the illustration, only one side is shown because the component parts and the removal/installation procedure are the same.

Fig 1: Rear Brake Area Replacement Components With Torque Specifications

Courtesy of HONDA, U.S.A., INC.

: Torque, N.m (lbf.ft)

: Replace

: Warning/Caution

: Inspection/Adjustment

*: Learning

: SPL Tool

: Required Removal

Courtesy of HONDA, U.S.A., INC.

: Torque, N.m (lbf.ft)	: Replace	: Warning/Caution	: Inspection/Adjustment	*: Learning	■: SPL Tool	: Required Removal
1: Type A2: Type B
