Inspection Outline

• The components to be tested are indicated by a dotted line.
• The illustration does not show all of the areas to be inspected.

Courtesy of HONDA, U.S.A., INC.

NOTICE:

For more efficient troubleshooting, you may be able to eliminate some inspection items as potential failures based on the conditions of the failure and vehicle.

• Check the low oil pressure warning message in the gauge control module with the engine running.
• • Warning message displays on:
  • Warning message not displayed:

Inspection Items		Work Items
-	Engine Oil Pressure	Do the Engine Oil Pressure Test - Refer to: Engine Oil Pressure Test(2.0L Engine) or Engine Oil Pressure Test(3.0L Engine)	o
-	Engine Oil	Do the Engine Oil Level Check - Refer to: Engine Oil Level Check or Engine Oil Replacement(2.0L Engine) or Engine Oil Replacement(3.0L Engine)	o
a	VTC Oil Control Solenoid Valve A (Bank 1)	Do the VTC Oil Control Solenoid Valve A (Bank 1) Test - Refer to: VTC Oil Control Solenoid Valve Test(3.0L Engine) or VTC Oil Control Solenoid Valve Test(2.0L Engine)		o
b	VTC Actuator A (Bank 1)	Do the VTC Actuator A (Bank 1) Inspection - Refer to: VTC Actuator Inspection(2.0L Engine) or VTC Actuator Inspection(3.0L Engine)		o
-	Timing Belt	Timing Belt Inspection		o
-	CMP Sensor A (Bank 1)	CMP Sensor A (Bank 1) Installation Inspection		o
-	CMP Pulse Plate A (Bank 1)	CMP Pulse Plate A (Bank 1) Visual Inspection		o
-	VTC System Oil Passage	VTC System Oil Passage Inspection		o
