Inspection Outline
The components to be tested are indicated by a dotted line.
Courtesy of HONDA, U.S.A., INC.
Inspection Items
Work Items
a
APP Sensor
APP Sensor Inspection
b
External Circuit
VCC4, APS1 Circuit Inspection
c
PCM
PCM Inspection
Courtesy of HONDA, U.S.A., INC.
