Transmission Identification

GWWA00-11081

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

The transmission code is located on the top of the transmission.

Example

PVQ = Transmission code
28.09.14 = production date September 28, 2014.
The rest of the dates depend on manufacturing.

Note

The transmission code is also on the vehicle data labels.

Vehicle Data Label Component Location:

A3/S3. Refer to VEHICLE DATA LABEL
TT. Refer to VEHICLE DATA LABEL
Q2. Refer to VEHICLE DATA LABEL
Q3. Refer to VEHICLE DATA LABEL
