Entertainment System Control Module: Locations

Passenger Compartment/Roof Component Views

Headliner Components




1 - Cargo Lamp
2 - Courtesy/Reading Lamp - Rear
3 - Infrared Module (U42+C3U)
4 - Courtesy/Reading Lamp - Center (U42+C3U)
5 - Digital Video Disc (DVD) Display (U42+C3U)
6 - Cellular Microphone (UE1)
7 - Courtesy/Reading Lamp - Front
8 - Console Flood Lamp
9 - Garage Door Opener (UG1)
10 - Vanity Mirror Lamp - Right (DH6)
11 - Inside Rearview Mirror
12 - Vanity Mirror Lamp - Left (DH6)
13 - Digital Video Disc (DVD) Display (U42-C3U)
14 - Courtesy/Reading Lamp - Center (-C3U)
15 - Infrared Module (U42-C3U)
16 - Rear Parking Assist (RPA) Display (UD7)
17 - Remote Control Door Lock Receiver (RCDLR)
