Installation Procedure

Courtesy of GENERAL MOTORS COMPANY

Auxiliary Battery Positive Cable (3) - Install

CAUTION:

Auxiliary Battery Positive Cable Fastener (2) @ Engine Wiring Harness Junction Block - Install and tighten - Engine Wiring Harness Junction Block Replacement (LTG) , or Engine Wiring Harness Junction Block Replacement (LGX)
Engine Wiring Harness Junction Block Cover (1) - Install
Courtesy of GENERAL MOTORS COMPANY

Auxiliary Battery Positive Cable (2) - Install
Auxiliary Battery Positive Cable Fastener (1) @ Battery Distribution Engine Compartment Fuse Block - Install and tighten - Battery Distribution Engine Compartment Fuse Block Replacement
Battery Distribution Engine Compartment Fuse Block Cover (3) - Install
Courtesy of GENERAL MOTORS COMPANY

Engine Control Module Bracket (1) - Install - Engine Control Module Replacement
Connect the battery negative cable. Battery Negative Cable Disconnection and Connection (3.6L LGX) , or Battery Negative Cable Disconnection and Connection (2.0L LTG)
