Note On Intermittents

Manipulate circuit No. 410 wiring, ECT sensor connector and PCM connector while observing PCM Data PD04. If engine coolant temperature jumps from normal reading to 298°F (148°C) or greater, repair intermittent short to ground on circuit No. 410. Remove and reconnect both ECT and PCM connectors and retest before replacing any components. If wiring and connectors are okay, substitute a known good ECT sensor and retest.

Fig 1: Code P014 Schematic (DeVille)

Courtesy of GENERAL MOTORS CORP.

Fig 2: Code P014 Flow Chart (DeVille)

Courtesy of GENERAL MOTORS CORP.
