Diagnostic Aids

An out-of-calibration A/C pressure sensor or A/C evaporator temperature sensor could cause Code 61 to set.

Fig 1: Code 61 Schematic (Fleetwood) A/C System Performance

Fig 2: Code 61 Flow Chart (Fleetwood) A/C System Performance
