Note On Intermittents
This code may set due to an intermittently sticking ISC motor.
Fig 1: Code P030 Schematic, ISC RPM Out Of Range
Courtesy of GENERAL MOTORS CORP
Fig 2: Code P030 Diagnostic Flow Chart - 1 Of 2, ISC RPM Out Of Range
Courtesy of GENERAL MOTORS CORP
Fig 3: Code P030 Diagnostic Flow Chart - 2 Of 2, ISC RPM Out Of Range
