Removal Procedure
WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2003 GMC Savana Special, 2003 GMC Savana Camper Special, 2003 GMC Savana, 2003 Chevrolet RV Cutaway, and 2003 Chevrolet Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
- Remove the front door trim plate (1). Refer to Door Trim Plate Replacement - Front .
- Remove the electrical connector (2) from the power mirror switch (9).
- Release the clip that retains the power mirror switch (9) to the front door trim plate (1).
- Remove the power mirror switch (9) from the front door trim plate (1).
