Installation Procedure

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2004 GMC Yukon XL, 2004 GMC Yukon, 2004 Chevrolet Tahoe, 2004 Chevrolet Suburban, and 2004 Chevrolet Avalanche. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the ambient light sensor to the underside of the IP top cover, turning it 1/4 turn to secure it in place.
  2. Connect the electrical connector (1) to the ambient light sensor on the underside of the IP top cover.
    3. Fig 1: View Of Ambient Light Sensor Electrical Connector
    GM350507Courtesy of GENERAL MOTORS CORP.
  3. Install the instrument panel top cover. Refer to Instrument Panel (I/P) Carrier Replacement in Instrument Panel, Gages and Console.
