Seat Horizontal Position Sensor - Driver Connector End View

Courtesy of GENERAL MOTORS CORP.
Connector Part Information		12059583 3 Way F Metri-Pack 150 Series (NAT)
Pin	Wire Color	Circuit No.	Function
A	BLK	782	Memory Seat Low Reference
B	-	-	Not Used
C	DK GRN	569	Horizontal Seat Motor Position Sensor Signal
D	GRY	788	5 Volt Reference
