Installation Procedure

    Fig 1: Removing Information Center Telltale Assembly Retaining Screws (EXT)
    GM818656Courtesy of GENERAL MOTORS CORP.
  1. Install the information telltale to the garnish molding.
    2. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the 2 retaining screws (1).

    Tighten:  Tighten the 2 screws to 2 N.m (18 lb in).

  3. Install the garnish molding. Refer to Garnish Molding Replacement - Rear Upper (Avalanche/Escalade EXT) or Garnish Molding Replacement - Rear Upper (Tahoe/Yukon/Escalade/Suburban) in Interior Trim.
