Installation Procedure

    Fig 1: View Of Seat Climate Control Module - Passenger Side
    GM1288830Courtesy of GENERAL MOTORS CORP.
  1. Connect harness connectors to the memory seat control module.
  2. Install the memory seat control module to the seat track assembly using the tie straps.
  3. Install the seat. Refer to Seat Replacement .
  4. Refer to Control Module References for programming and setup information.
