Installation Procedure

Fig 1: View Of Power Steering Gear Outlet Pipe/Hose & Components (With Hydroboost)

Courtesy of GENERAL MOTORS CORP.

Install the power steering gear outlet pipe (6) to the power steering gear (2).
Install the retaining clamp.
Fill and bleed the power steering system. Refer to Power Steering System Bleeding .
Inspect all the hose connections for leaks.
