Installation Procedure

    Fig 1: View Of Theft LED & Electrical Connector
    GM1271176Courtesy of GENERAL MOTORS CORP.
  1. Connect the theft LED to the electrical connector.
  2. Press the theft LED to the opening in the door trim panel.
