Air Cleaner Bracket Replacement

Fig 1: Air Cleaner Bracket

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
Preliminary Procedure: Remove the air cleaner assembly. Refer to Air Cleaner Assembly Replacement .
1	Air Cleaner Bracket Fastener (Qty: 4) CAUTION: Refer to Fastener Caution Tighten: 10 N.m(89 lb in)
2	Air Cleaner Bracket
