Transfer Case Front
WARNING: This page is about a different variant/trim than selected.
| Callout | Component Name |
|---|---|
| 1 | Transfer Case Input Shaft Seal |
| 2 | Transfer Case Front Output Shaft Flange |
| 3 | Transfer Case Rear Output Shaft Oil Slinger |
| 4 | Transfer Case Front Output Shaft Flange Retaining Ring |
| 5 | Transfer Case Fill Plug |
| 6 | Transfer Case Four Wheel Drive Actuator Seal |
| 7 | Transfer Case Four Wheel Drive Actuator O-Ring Seal |
| 8 | Transfer Case Four Wheel Drive Actuator |
| 9 | Transfer Case Four Wheel Drive Actuator Bolt [2x] |
