A/Trans Case Extension Assembly (Two Wheel Drive)

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
400	1-2-3-4-5-Reverse Clutch Piston Dam Retaining Ring
401	1-2-3-4-5-Reverse Clutch Piston Dam Seal
402	1-2-3-4-5-Reverse Clutch Piston Dam
405	1-2-3-4-5-Reverse Clutch Piston Return Spring
406	1-2-3-4-5-Reverse Clutch Piston
407	Automatic Transmission Case Hole Plug
408	1-2-3-4-5-Reverse Clutch Piston Outer Seal
409	1-2-3-4-5-Reverse Clutch Piston O-Ring Seal
410	1-2-3-4-5-Reverse Clutch Piston Inner Seal
411	Automatic Transmission Case Extension
414	Propeller Shaft Transmission Flange Fluid Seal
415	Output Shaft Bearing
