Power Steering System Block Diagram Identification
| Callout | Component Name |
|---|---|
| B60 | B60 Passenger Presence Sensor |
| B153D | B153D Seat Belt Buckle - Driver |
| S64P | S64P Seat Adjuster Switch - Passenger |
| K85 | Passenger Presence Module |
| K36 | K36 Inflatable Restraint Sensing and Diagnostic Module |
| A11 | A11 Radio |
| P16 | P16 Instrument Cluster |
| K124 | Active Safety Control Module |
| M101L | Seat Belt Retractor Motor Module - Left |
| M101R | Seat Belt Retractor Motor Module - Right |
| P14 | P14 Passenger Air Bag Disabled Indicator |
