Left Rear of Engine Compartment Components

Items
1: B20 Brake Fluid Level Switch B20 Brake Fluid Level Switch
2: M75 Windshield Wiper Motor M75 Windshield Wiper Motor
3: K17 Electronic Brake Control Module K17 Electronic Brake Control Module
4: X50D Fuse Block - Battery X50D Fuse Block - Battery X1 X50D Fuse Block - Battery X2 X50D Fuse Block - Battery X3 X50D Fuse Block - Battery X4 (KL9)X50D Fuse Block - Battery X5 X50D Fuse Block - Battery X6 X50D Fuse Block - Battery X7 X50D Fuse Block - Battery X7 (without KL9)
5: X50A Fuse Block - Underhood X50A Fuse Block - Underhood X1 X50A Fuse Block - Underhood X2 X50A Fuse Block - Underhood X3 X50A Fuse Block - Underhood X4 X50A Fuse Block - Underhood X5 (KL9)X50A Fuse Block - Underhood X6
6: C1 Battery C1 Battery C1 Battery - (Battery Negative) (without KL9)C1 Battery
7: B18 Battery Current Sensor B18 Battery Current Sensor KL9 B18 Battery Current Sensor
8: K20 Engine Control Module K20 Engine Control Module X1 K20 Engine Control Module X2 K20 Engine Control Module X3
9: B19B Brake Booster Vacuum Sensor (FX3) B19B Brake Booster Vacuum Sensor

Fig 1: Left Rear of Engine Compartment Components

Courtesy of GENERAL MOTORS COMPANY
