Removal Procedure

  1. GM4676959Courtesy of GENERAL MOTORS COMPANY

    Place masking tape over the outside rearview mirror glass.(1)

  2. GM4676960Courtesy of GENERAL MOTORS COMPANY

    Carefully push the outside rearview mirror glass (1) upward and into the inside corner of the mirror housing.

  3. GM4676962Courtesy of GENERAL MOTORS COMPANY

    Grasp the bottom edge of the outside rearview mirror glass firmly.(1)

  4. GM4677107Courtesy of GENERAL MOTORS COMPANY

    lift up on the outside rearview mirror glass (1) and pull rearward until the outside rearview mirror glass retainers release from the actuator motor ring.(2)

  5. Disconnect the electrical connectors.
