Automatic Transmission/Transaxle

SCHEMATICS AND DIAGRAMS

Drive (First) Half Throttle:




Drive (Second) Half Throttle:




Drive (Third) Not Locked Up:




Drive (Third) Lock-Up:




Drive (Kickdown) Part Throttle:




Second (Manual) Closed Throttle:




Low (Manual) Closed Throttle:




Reverse:
