Removal

5.7L





The Camshaft Position Sensor (CMP) (3) is located on right side of timing gear/chain cover below generator (1).

1. Disconnect electrical connector (3) at CMP sensor.





2. Remove sensor mounting bolt (3).

3. Carefully twist sensor (2) from timing gear/chain cover.

4. Check condition of sensor O-ring.
