FAN, Cooling: Installation: Installation
| 1 - RADIATOR FAN ASSEMBLY |
| 2 - ELECTRICAL CONNECTOR |
| 3 - UPPER RADIATOR HOSE |
- Position fan motor on radiator fan shroud.
- Install mounting bolts. Tighten to 10 N.m (89 in. lbs.).
- Position fan blade on motor and install retaining nut. Tighten nut to 25 N.m (221 in. lbs.).
- Position radiator cooling fan assembly (1) in vehicle.
- Install cooling fan mounting bolts. Tighten to 6 N.m (50 in. lbs.)
- Connect cooling fan electrical connector (2).
- Install upper radiator hose (3).
- Install the air filter housing. Refer to Engine/Air Intake System/BODY, Air Cleaner - Installation .
- Fill the cooling system. See Cooling - Standard Procedure .
- Operate engine until it reaches normal operating temperature. Check cooling system and automatic transmission for correct fluid levels.
