45RFE/545RFE Automatic Transmission






SPECIFICATIONS

GENERAL






GEAR RATIOS






TORQUE SPECIFICATIONS






FLEX PLATE





Flexplate-to-crankshaft bolts 95 Nm (70 ft. lbs.)
