Rear Window Power Sunshade Module - Installation

INSTALLATION




Position the SunShade Module (SSM) at the rear sunshade assembly.
1. Slide the module onto the mounting bracket and engage the retaining clip.
2. Connect the electrical connector.
3. Install the package tray trim panel, Rear Shelf Panel - Installation.
4. Connect the negative battery cable.
