Boost Pressure Sensor: Installation

Fig 1: PEDAL AND APPS SENSOR
GC0055506Courtesy of CHRYSLER LLC
  1. Install the boost pressure sensor (3) in the charge air tube (4).
  2. Install the 2 mounting bolts (2). Tighten to 8 Nm/6 lb-ft.
  3. Reconnect the electrical connector (1).
  4. Install the belly pan.
  5. Reconnect negative battery cable.
