System Specifications
















TRANSMISSION FILL

To avoid overfilling transmission after a fluid change or overhaul, perform the following procedure:

1. Verify that the vehicle is parked on a level surface.
2. Remove the dipstick tube cap.
3. Add following initial quantity of MOPAR(R) CVTF+4, Automatic Transmission Fluid, to the transmission:
a. If only fluid and filter were changed, add 7.0 L (14.8 pts.) of transmission fluid to transmission.
b. If the transmission was completely overhauled or the torque converter was replaced or drained, add 8.1 L (17.1 pts.) of transmission fluid to transmission.
4. Check the transmission fluid Check Oil Level and adjust as required.
