Module-Drive Train Control C1 (D3872A)

Harness-Family: Body

Color: BLUE

Gender: FEMALE

Part Number: 7283-6456-90

Part Description: KAIZEN YESC SUB ASSEMBLY

Connector No: D3872A

Option: Standard

Repair Kit Part Number: 68065019AA

Cavity Count: 16

Fig 1: Module-Drive Train Control C1 Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Drive Train Control C1 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T301

DG/GY

SWITCHED BATTERY SOLENOID SUPPLY

N/A

T313

YL/LG

MODE SENSOR SIGNAL

N/A

F943

PK/LG

FUSED IGNITION RUN-START CONTROL OUTPUT

N/A

D51

WT/BR

CAN C (-)

N/A

D52

WT/LB

CAN C (+)

N/A

T317

YL/TN

STEP MOTOR CONTROL D

N/A

K594

BR/LG

DRIVETRAIN SENSOR RETURN

N/A

K504

DRIVETRAIN 5 VOLT SUPPLY

N/A

⁽¹⁾	Pins not listed are not used for this connector
