Pcm - Removal

WARNING: This page is about a different car, the 2012 Dodge Caliber. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Retainers, Fresh Air Inlet Duct & Air Cleaner Body
GC0145275Courtesy of CHRYSLER GROUP, LLC
  1. Remove the air intake duct.
  2. Disconnect negative battery cable.
    Fig 2: Electrical Connectors, PCM, Three Mounting Bolts & Ground Wire
    GC0145274Courtesy of CHRYSLER GROUP, LLC
  3. Disconnect the Powertrain Control Module (PCM) harness connectors (2) by pressing in the locking tab and lift the lever.
  4. Remove bolts (3) and the PCM (4) from the air cleaner housing.
