Module-Drive Train Control C2 (D3872B)

Harness-Family: Body

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 15466671

Part Description: GT SERIES CONNECTOR ASSEMBLY

Connector No: D3872B

Option: Standard

Repair Kit Part Number: 68065020AA

Cavity Count: 4

Fig 1: Module-Drive Train Control C2 Connector End View
GCWD1006537Courtesy of CHRYSLER
Fig 2: Module-Drive Train Control C2 Component Location
GCWD1183589Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
A T316 YL 14 SHIFT MOTOR CONTROL B N/A
B T315 YL 14 SHIFT MOTOR CONTROL A N/A
C A959 YL 14 FUSED B(+) N/A
D Z916 BK 14 GROUND N/A
