Module-Passive Entry C2 (D2505B)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 14520152

Part Description: Not Available

Connector No: D2505B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 12

Fig 1: Module-Passive Entry C2 Connector End View

GCWD1025406

Courtesy of CHRYSLER

Fig 2: Module-Passive Entry C2 Component Location

GCWD1183723

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
B1	D920	GY	22	PASSIVE ENTRY ANTENNA 1 SIGNAL	N/A
B2	D921	GY	22	PASSIVE ENTRY ANTENNA 1 RETURN	N/A
B3	D922	GY	22	PASSIVE ENTRY ANTENNA 2 SIGNAL	N/A
B4	D923	GY	22	PASSIVE ENTRY ANTENNA 2 RETURN	N/A
B5	D924	GY	22	PASSIVE ENTRY ANTENNA 3 SIGNAL	N/A
B6	D925	GY	22	PASSIVE ENTRY ANTENNA 3 RETURN	N/A
B7	D926	GY	22	PASSIVE ENTRY ANTENNA 4 SIGNAL	N/A
B8	D927	GY	22	PASSIVE ENTRY ANTENNA 4 RETURN	N/A
