Module-Steering Control C1 (D3816A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 1924396-1

Part Description: 14P MCON 1.2 SCCM INNER HOUSING - OUTER HOUSING YELLOW

Connector No: D3816A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 14

Fig 1: Module-Steering Control C1 Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Steering Control C1 Component Location

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
A1	D51	WT	22	CAN C (-)	N/A
A10	R61	LG	20	DRIVER SQUIB 2 LINE 2	N/A
A11	R63	LG	20	DRIVER SQUIB 2 LINE 1	N/A
A2	D52	WT	22	CAN C (+)	N/A
A3	Z912	BK	20	GROUND	N/A
A4	A909	RD	20	FUSED B(+)	N/A
A6	C986	GY	20	HEATED STEERING WHEEL RETURN	N/A
A7	C91	DB	20	HEATED STEERING WHEEL FEED	N/A
A8	R43	LG	20	DRIVER SQUIB 1 LINE 2	N/A
A9	R45	LG	20	DRIVER SQUIB 1 LINE 1	N/A
