Module-Powertrain Control C1 (D3838A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 9-1326726-8

Part Description: NGC (ALL CAVITIES OPEN) - INDEX A

Connector No: D3838A

Option: Standard

Repair Kit Part Number: 05083222AA

Cavity Count: 38

Fig 1: Module-Powertrain Control C1 Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Powertrain Control C1 Component Location

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	K98	DB	16	COIL CONTROL 8	5.7L
10	A209	RD	18	FUSED B(+)	N/A
11	F202	PK	20	IGNITION RUN/START CONTROL OUTPUT	N/A
12	F1	PK	20	IGNITION OFF/RUN/START CONTROL OUTPUT	5.7L
13	K444	DB	20	CMP SIGNAL 3	3.6L
14	K917	BR	20	SENSOR GROUND	N/A
15	K276	DB	20	VVT EXHAUST CONTROL	3.6L
17	K277	DB	20	VVT EXHAUST CONTROL 2	3.6L
18	Z903	BK	16	GROUND	N/A
19	Z903	BK	16	GROUND	N/A
2	K76	BR	20	VVT INTAKE CONTROL	3.6L
20	G6	VT	20	OIL PRESSURE SIGNAL	N/A
22	N7	DB	20	FUEL TANK PRESSURE SIGNAL	N/A
24	A803	GY	18	GEN SENSE	N/A
27	K856	BR	20	5 VOLT SUPPLY	N/A
28	K452	BR	20	MDS SOL CONTROL 4	5.7L
29	A209	RD	18	FUSED B(+)	N/A
3	K97	BR	16	COIL CONTROL 7	5.7L
31	K141	DB	20	O2 1/2 SIGNAL	N/A
32	K902	BR	20	O2 RETURN (UPSTREAM)	N/A
33	K243	BR	20	O2 2/2 SIGNAL	N/A
34	D65	WT	20	CAN C (+)	N/A
35	D64	WT	20	CAN C (-)	N/A
36	K445	DB	20	CMP SIGNAL 4	3.6L
38	F342	BR	16	ASD CONTROL OUTPUT	N/A
4	K28	BR	16	INJECTOR CONTROL 8	5.7L
5	K26	BR	16	INJECTOR CONTROL 7	5.7L
9	Z903	BK	16	GROUND	N/A
