Module-Transmission Control C2 (D3855B)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 965224-1

Part Description: CONNECTOR - JPT KONTAKT SYSTEM

Connector No: D3855B

Option: Standard

Repair Kit Part Number: 68040483AA

Cavity Count: 12

Fig 1: Module-Transmission Control C2 Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Transmission Control C2 Component Location

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
12	T70	YL	20	INPUT SPEED 1 (N2) SIGNAL	N/A
13	T72	YL	20	SENSOR SUPPLY	N/A
14	T60	YL	20	OD CONTROL (RFE)/1-2/4-5 SOLENOID CONTROL (NAG1)	N/A
15	T73	GY	20	3-4 SOLENOID CONTROL	N/A
16	T74	YL	20	2-3 SOLENOID CONTROL	N/A
17	T75	YL	20	TCC SOLENOID CONTROL	N/A
33	T13	DG	20	SPEED SENSOR GROUND	N/A
34	T54	VT	20	TRANSMISSION TEMPERATURE SIGNAL	N/A
35	T71	YL	20	INPUT SPEED 2 (N3) SIGNAL	N/A
36	T76	YL	20	MODULATION PRESSURE CONTROL	N/A
37	T77	YL	20	SHIFT PRESSURE CONTROL	N/A
38	T78	YL	20	SOLENOID SUPPLY	N/A
