Module-Integrated Center Stack Switch Bank (D2695A)

Harness-Family: IP

Color: BLACK

Gender: MALE

Part Number: 30700-1081

Part Description: Not Available

Connector No: D2695A

Option: ~~

Repair Kit Part Number: Not Available

Cavity Count: 8

Fig 1: Module-Integrated Center Stack Switch Bank Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Integrated Center Stack Switch Bank Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D462

0.5

CAN IHS (-)

N/A

L91

WT/DB

0.35

HAZARD SWITCH SENSE

N/A

Z912

0.35

GROUND

N/A

A937

0.35

FUSED B(+)

N/A

D463

0.5

CAN IHS (+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
