Module-Drive Train Control C2 (D3872B)

Harness-Family: Suspension_Jumper

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 15466671

Part Description: GT SERIES CONNECTOR ASSEMBLY

Connector No: D3872B

Option: Standard

Repair Kit Part Number: 68065020AA

Cavity Count: 4

Fig 1: Module-Drive Train Control C2 Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Drive Train Control C2 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A194

FUSED B(+)

N/A

T315

YL/BR

SHIFT MOTOR CONTROL A

N/A

T316

YL/GY

SHIFT MOTOR CONTROL B

N/A

Z901

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
